Optical cable flexing testing machine




This equipment is suitable for testing optical cable (such as elevator optical cable) withstand the ability of repeated flexing in operation, by applying repeated flexing force, for qualified optical cable requirements optical fiber does not break, optical fiber attenuation change does not exceed the value specified in the detailed specification of optical cable products, optical cable sheath does not crack, cable core component is not damaged


Item spec.

Product model

GFKR-1000

Flexing travel

1000mm

Flexing wheel travelling speed

(100~350) mm/s, set arbitrarily

Flexing counts

1~9999, set arbitrarily

Hammer bracket weight

5kg×2

Hammer weight

two sets of weight hammer, each comprise: 5kg×4,2.5kg×1, 1.0kg×1

Diameter of guiding wheel

200mm, 250mm, 300mm

Equipment weight

About 900kg
